CHKQ203/75 Washed Up Tong for Inclined Well

Category Handling Tools

Head tong and back tong are all planetary paw clamping machine, each one owning four. There is no need to change parts when the pipe diameter is in the corresponding clamping range.

Parameter of CHKQ203/75 Washed Up Tong for Inclined Well

Characteristics：

Head tong and back tong are all planetary paw clamping machine, each one owning four. There is no need to change parts when the pipe diameter is in the corresponding clamping range.

The drive gear, an enclosed system can keep itself good lubrication from drilling fluids.

We can make remote operation and hydraulic control concerning the switch of makeup and breakout.

There are sewage holes drilled in the rotatory space of die plates which are available for the vertical well and inclined well over the makeup and breakout of pipe.

Rise and fall of single oil cylinder can make the clamping position adjustable and compact while forward and withdraw of air cylinder can make the tong stretch with elasticity, eliminating deviation.

1	Available Range	140～203 mm
2	Rated Torque @2030PSI / 14 MPa	55310 ft·lbs/ 75000 N·m
3	Nominal Speed @40GPM / 150 LPM	4 RPM
4	Maximum Oil Supply	20300 PSI @40 GPM / 14 MPa @150 LPM
5	Rated Air Supply Pressure	73~131 PSI / 0.5~0.9 MPa
6	Maximum Thrust Distance of Tong	27″ / 700 mm
7	Rise and Fall Range of The Tong	0~14″ / 0~360 mm
8	Washed-up Corner One Time	30°
9	The Available Corner of Inclined Well	0～45°
10	Boundary Dimension(L×W×H)	66.6″×45.7″×43″ / 1692×1162×1090 mm
11	Weight	3970 lbs / 1800 kg
